Connection Layout for Flame Control Units
Attach the main power leads directly to the control terminals using 15-amp rated connectors to prevent overloads and ensure consistent ignition of the burner system.
Organize sensor and switch lines along the frame to maintain stable operation of the detection mechanisms. Keep all conductors away from heat sources and moving parts to minimize shorts and damage.
Labeling and Identification
Use color-coded insulation and heat-resistant tags to mark polarity, power, ground, and signal lines. Clear labeling simplifies maintenance and reduces the risk of improper connections during service.
Protection and Routing
Install flexible metal conduits around exposed sections near the burner and pilot assembly. These conduits resist abrasion and thermal stress while maintaining secure routing of all control and power lines.
Identifying Power Supply and Safety Switch Connections
Connect the main voltage leads directly to the terminal block rated for 120V or 240V, depending on the model. Ensure that the grounding conductor is secured to the metal frame to prevent electrical faults, and keep live wires clearly separated from control sensors to avoid accidental shorts.
Safety Switch Integration
Route the cutoff and limit switches in line with the main feed using insulated connectors with strain relief. Test each switch manually to confirm that it interrupts current as intended, providing reliable protection in case of overheating or system malfunction.
