LED Module Installation and Connection Guide
Begin by turning off the main power supply to prevent accidental shocks. Confirm that the circuit is de-energized using a voltage tester before touching any conductors.
Identify each terminal on the control unit carefully. The line input carries incoming current, the load output goes to the fixtures, and the neutral is required for module operation. Mark each wire to avoid confusion.
Strip insulation precisely from the ends of each conductor to expose about 3/8 inch of copper. Ensure no stray strands can cause a short circuit between adjacent terminals.
Attach the grounding conductor securely to the metal box or dedicated screw. A solid ground connection reduces interference and prevents electrical noise that can affect module performance.
Connect the line and load wires to the appropriate terminals using firm screws or push-in connectors. The module should sit flush within the wall box without pinching any cables.
Test the device with a single fixture first to ensure proper functionality. Gradually increase the load, observing for flickering or unusual noise. Adjust connections if the control is unstable.
For multi-location operation, link traveler conductors between modules following the same polarity. Use wire nuts or connectors rated for the conductor gauge and maintain consistent labeling throughout.
Secure the faceplate and restore power. Operate the control incrementally to verify smooth intensity adjustment and confirm all connected fixtures respond correctly without buzzing or dimming irregularities.
Identifying Terminals and Lead Functions
Start by labeling each connector before installation. The hot input carries incoming current, the load output directs energy to fixtures, and the neutral lead completes the circuit. Misidentifying these can cause malfunction or flickering.
Examine the traveler and control leads carefully for color coding and markings. Black or red usually indicate power paths, while white is neutral. Maintain consistency across all modules to prevent reversed polarity or interference with control features.
Test each lead with a voltage detector before final attachment. Confirm that the incoming feed and outgoing path correspond correctly to the device terminals, and that the neutral and ground connections are continuous. Accurate identification ensures safe operation and smooth intensity regulation.
